Instruções de utilização
de largura.
(Tenha em consideração que o porta-
bagagens pode ser retirado antes de
colocar a criança na cadeira.)
- Não pode ser montada em bicicletas
equipadas com amortecedores.
- Pode ser montada em bicicletas com
ou sem porta-bagagens.
Caso tenha dúvidas quanto à
possibilidade de instalação da cadeira,
recomendamos obter informações junto
do distribuidor da bicicleta.
- O assento só deve ser montado em
bicicletas adequadas para este tipo de
carga. Consulte o fornecedor da sua
bicicleta para obter informações
detalhadas.
- Certifique-se de que os parafusos da
abraçadeira estão apertados, e efetue
uma verificação periódica.
- A cadeira está montada no tubo da
bicicleta com a abraçadeira (6).
Consulte a imagem F. Os parafusos
devem estar bem apertados para fixar
a cadeira de forma segura e evitar que
esta escorregue.
Tenha por hábito certificar-se de que os
parafusos estão bem apertados antes
de cada utilização da bicicleta.
- Para maior conforto e segurança da
criança, certifique-se de que a cadeira
não se inclina para a frente de forma a
que a criança não tenha tendência para
deslizar.
A Hamax recomenda que a cadeira se
incline ligeiramente para trás.
- Verifique que todas as peças da
bicicleta funcionem corretamente com a
cadeira de bicicleta montada.
UTILIZAÇÃO
- Normalmente, para transportar uma
criança numa bicicleta, o ciclista deverá
ter mais de 16 anos. Verifique a
legislação e as normas nacionais a
respeito.
- A cadeira é aprovada para utilização
por crianças dos 9 meses aos 6 anos ou
de peso máximo até 22 kg. Certifique-
se, de tempos a tempos, de que verifica
que o peso e tamanho da criança não
excedem a capacidade máxima da
cadeira.
- Não transporte uma criança que seja
demasiado jovem para ser transportada
com segurança, tendo em conta a idade
mínima recomendada. Transporte
apenas crianças que são capazes de se
sentar sozinhas por um longo período
de tempo, durante pelo menos o
percurso da viagem de bicicleta.
- Certifique-se de que não é possível
que nenhuma parte do corpo ou roupa
da criança entre em contacto com
qualquer da cadeira ou da bicicleta
parte que se encontre em movimento e
volte a fazer verificações à medida que
a criança cresce, devido ao perigo de
encarceramento dos pés na roda e dos
dedos nos mecanismos de travão e
selins com molas. A cadeira oferece
ampla segurança lateral. No entanto,
recomendamos adquirir e instalar um
protetor de roda/protetor de corrente.
Poderá adquirir estes acessórios junto
do seu distribuidor.
- Certifique-se de que não há objetos
pontiagudos na bicicleta que possam
ferir a criança.
- Certifique-se de que o sistema de
aperto não está solto nem é passível de
ficar preso em partes movíveis, em
especial nas rodas, incluindo quando a
bicicleta é conduzida sem a cadeira de
criança.
- Utilize sempre o sistema de cinto/
aperto de segurança de forma a
certificar-se de que a criança vai presa
à cadeira.
- A criança sentada na cadeira da
bicicleta deverá estar protegida com
roupas mais quentes do que as do
ciclista.
- A criança deve estar protegida contra
a chuva com vestuário impermeável
adequado.
- Lembre-se de colocar o capacete na
criança antes de iniciar o passeio.
- Lembre-se de que a cadeira pode
aquecer muito quando exposta ao sol.
Verifique a sua temperatura antes de
acomodar a criança.
- Quando transporta a bicicleta de carro
(no exterior do mesmo) remova a
cadeira. A turbulência do ar pode
danificar a cadeira ou libertá-la da
bicicleta, o que pode provocar um
acidente.
AVISOS
- Aviso: Não junte bagagem ou
equipamento extra à cadeira de criança,
pois pode fazer com que o peso total
exceda os 22 kg. Recomendamos que a
bagagem extra seja acoplada à frente
da bicicleta.
- Aviso: Não altere a cadeira de criança.
Isto invalidará a garantia e a
responsabilização por parte do
fabricante.
- Aviso: Lembre-se de que o peso da
criança pode alterar a estabilidade da
bicicleta e as suas propriedades de
manobra, principalmente durante a
condução e a utilização dos travões.
- Aviso: Nunca deixe a bicicleta
estacionada com uma criança na
cadeira sem qualquer vigilância.
- Aviso: Não utilize a cadeira, caso haja
peças partidas ou avariadas.
- Cubra qualquer mola posterior do
selim que esteja exposta.
MANUTENÇÃO
- Use apenas sabão e água morna para
a limpeza da cadeira.
- Caso haja um acidente ou dano
envolvendo a cadeira, entre em
contacto com o seu distribuidor para
avaliar se ainda pode ser utilizada. Os
componentes danificados devem ser
substituídos. Consulte o seu distribuidor
caso tenha dúvidas sobre a instalação
dos novos componentes.
Sugestão! Se desejar utilizar a cadeira
em duas bicicletas diferentes, poderá
adquirir componentes de fixação
adicionais junto do seu distribuidor.
Desejamos-lhe um ótimo passeio!
Saudações da equipa Hamax.
