FR
1. Siègeprincipal
2. Systèmedeharnais
3. Fermeturedeceinture
4.Supportsdepieds
5. Arcporteur
6.Étrierdefixationcomplet
a)Étrier
b)Sanglesmétalliques
c)Visdefixation
d)Indicateurdesécurité
7. Tigeexcentrique
8. Protectiondepied
DE
1. Sitz
2. Rückhaltesystem
3. Gurtverschluss
4. Fußstützen
5. Trägerbogen
6. KompletteBefestigungsklammer
a)Klammer
b)Metallstreifen
c)Befestigungsschrauben
d)Sperrenanzeige
7. Exzenterwelle
8. Radkontaktschutz
NO
1. Hovedsete
2. Sikkerhetssele
3.Beltelås
4.Fotstøtter
5.Bærebøyle
6.Festebeslagkomplett
a)Brakett
b)Metallbånd
c)Festeskruer
d)Låsindikator
7.Låsepinne
8.Ekstraeikebeskyttelse
CZ
1. Sedačka
2.Zádržnýsystém
3. Posuvnéopěradlo
3.Bezpečnostnípřezka
4.Podporyproboty
5.Připevňovacírám
6.Kompletníupevňovacítřmen
a)třmen
b)kovovépásy
c)upevňovacíšrouby
d)indikátorzajištění
7. Excentrickýhřídel
8. Ochrananohou
DK
1. Sæde
2.Fastspændingssystem
3.Bæltelås
4.Fodstøtter
5.Bærebue
6.Kompletmonteringsbeslag
a)Beslag
b)Metalbånd
c)Fastgørelsesskruer
d)Sikkerhedslås
7. Ekscenteraksel
8. Fodbeskyttelse
ES
1. Asientoprincipal
2.Sistemaderetención
3. Respaldoregulable
3.Cierredelcinturón
4.Reposapiés
5.Horquillasustentadora
6.Soportedesujecióncompleto
a)Soporte
b)Tirasmetálicas
c)Tornillosdefjiación
d)Indicadordeseguridad
7. Ejeexcéntrico
8. Protecciónparalospies
FI
1. Istuin
2.Turvakiinnitysjärjestelmä
3.Vyönlukkosolki
4.Jalkatuet
5. Kantokaari
6.Kiinnityspidikekokonaisena
a)Pidike
b)Metalliliuskat
c)Kiinnitysruuvit
d)Turvamerkinnät
7. Epäkeskoakseli
8. Jalkasuoja
HR
1. Sjedalica
2.Zateznisustav
3.Kopča
4.Osloncizastopala
5.Stremennosača
6.Zateznidržačpotpuni
a)držač
b)metalnetrake
c)zateznivijci
d)sigurnosnipokazivač
7. Ekscentričnovratilo
8. Štitnikstopala
HU
1. Gyermekülés
2.Biztonságiöv
3.Övrögzítő
4.Lábtartó
5.Tartórúd
6.Teljesrögzítőkonzol
a)Konzol
b)Fémlemez
c)Rögzítőcsavarok
d)Biztosításjelző
7. Excentrikustengely
8. Lábvédő
IT
1. Seggiolinoprincipale
2.Cinturedisicurezza
3. Fibbia
4.Poggiapiedi
5.Staffadisostegno
6.Attaccocompleto
a) Attacco
b)Fascettemetalliche
c)Vitidifissaggio
d)Indicatoredisicurezza
7. Assaleeccentrico
8. Protezioneperpiedi
KR
1. 메인 시트
2. 안전 벨트
3. 버클
4. 풋 레스트
5. 캐리어 보우
6. 고정 브래킷 체결부
a) 브래킷
b) 메탈 스트립
c) 고정 나사
d) 안전 표시부
7. 잠금 핀
8. 풋 가드
