V-CD600BT

Detach the unit

Removing the panel Attaching the panel

Note: DO NOT insert the D.C.P from the left side. Doing so may damage it. The D.C.P can easily be damaged by shocks.

After removing it, place it in a protective case and be careful not to drop it or subject it to strong shocks. When the release

button is pressed and the D.C.P is unlocked, the car's vibrations may cause it to fall. To prevent damage to the D.C.P,

always store it in a protective case after detaching it. Be careful not to damage it by pressing on it with fingernails, pens,

screwdrivers, etc.

Cleaning

If the D.C.P is dirty, wipe off the dirt with soft, dry cloth only. And use a cotton swab soaked in isopropyl

alcohol to clean the socket on the back of the D.C.P.

Resetting the unit:

After releasing the front panel, use a pencil or any non-metallic object to press & hold the RESET button

for five seconds to reset the unit.

1. Attach the panel at the right side first, with point B on the

main unit touching point A on the D.C.P. (As shown on the

diagram).

2. Then press the left side of D.C.P. onto the main unit until a

“click” sound is heard.

1. Turn the power off

2. Press the D.C.P. release button

3. Remove the D.C.P.
