Power Modules
3.2 Power Modules Blocksize Liquid Cooled (PM340)
Manual
Manual, 01/2011, 6SL3097-4AC10-0BP2
105
Power Module frame size FSF Liquid Cooled
3.2.2 Safety information
CAUTION
During transport and during storage, Power Modules must be protected against mechanical
shock and vibration. It is also important to protect the unit against water (rain) and against
excessively high/excessively low temperatures.
Note
Connection authorization
Power Modules have been designed for use in the industrial environment and generate
current harmonics on the line side as a result of the rectifier circuit.
When a machine with integrated Power Modules is connected to the public network,
authorization is required from the local power supply company if the rated input current of the
machine does not fulfill the requirements of EN 61000-3-2 with respect to current harmonics.
