Siemens 6SL3210-1SE27-5UA0 [118/318] Connection to the cooling circuit
![Siemens 6SL3210-1SB11-0UA0 [118/318] Connection to the cooling circuit](/views2/1587218/page118/bg76.png)
Power Modules
3.2 Power Modules Blocksize Liquid Cooled (PM340)
Manual
118 Manual, 01/2011, 6SL3097-4AC10-0BP2
DANGER
Once the terminal cover has been removed, the degree of protection of the Power Module
is reduced to IP00.
3.2.6 Connection to the cooling circuit
The coolant connection for SINAMICS units is established by means of a 1/2'' screwed joint.
The supply and return lines must be connected using a flexible, non-conductive hose, in
order to
● Prevent electrochemical corrosion,
● Reduce the transmission of vibrations, and
● Dampen pressure transients in the coolant.
The hose should be about 1.5 m in length (total of supply and return lines).
For information about the coolant and the configuration of the cooling circuit, refer to the
chapter titled "Cooling circuit and coolant properties".
3.2.7 Commissioning
Prior to commissioning
Once the devices have been installed and before they are commissioned, the cooling circuit
must be checked for leaks.
After commissioning
The recommended servicing procedure for the cooling circuit is to check the fill level and the
coolant for discoloration or cloudiness at least once a year.
If the coolant level has dropped, the loss should be corrected on closed or semi-open circuits
with a prepared mixture of distilled water and inhibitor or Antifrogen N.
