![Siemens 6SL3210-1SE27-5UA0 [241/318] Blocksize power modules with screening kits](/img/pdf.png)
Siemens 6SL3210-1SE27-5UA0 [241/318] Blocksize power modules with screening kits
![Siemens 6SL3210-1SE31-1UA0 [241/318] Blocksize power modules with screening kits](/views2/1587218/page241/bgf1.png)
Accessories
8.3 Screening Kit
Manual
Manual, 01/2011, 6SL3097-4AC10-0BP2
241
8.3.2.2 Blocksize Power Modules with Screening Kits
Dimension drawings of Power Modules with Screening Kit, frame sizes FSA to FSF
Figure 8-12 Dimension drawing of PM340 Power Module with Screening Kit, frame size FSA, all
dimensions in mm and (inches)
