Power Modules
3.2 Power Modules Blocksize Liquid Cooled (PM340)
Manual
110 Manual, 01/2011, 6SL3097-4AC10-0BP2
Arrangement of the line and motor terminals
The following diagram shows the arrangement of the line and motor terminals for PM340
Power Modules (frame sizes FSD to FSF). The diagram also includes the terminal tightening
torques.
)UDPHVL]HV)6'WR)6)
)UDPHVL]HV)6')6(
01P
)UDPHVL]H)6)
01P
Figure 3-33 Arrangement of the line supply and motor terminals for the PM340
3.2.3.3 Line supply connection
Table 3- 16 Terminal block, line supply connection 3-ph. 380 V - 480 V AC
Terminal Signal name Technical specifications
1 U1/L1 External conductor L1
2 V1/L2 External conductor L2
3 W1/L3 External conductor L3
4 PE PE connection
