Accessories
8.2 DRIVE-CLiQ coupling
Manual
Manual, 01/2011, 6SL3097-4AC10-0BP2
235
8.2 DRIVE-CLiQ coupling
8.2.1 Description
The DRIVE-CLiQ coupling is used to connect two DRIVE-CLiQ cables in accordance with
degree of protection IP67 acc. to EN 60529.
In addition to the data lines, the power supply contacts of DRIVE-CLiQ are also routed via
the coupling.
You can find information on the permissible cable length in the chapter "DRIVE-CLiQ signal
cables".
8.2.2 Safety information
Note
Only cables from Siemens may be used for DRIVE-CLiQ connections.
8.2.3 Interface description
8.2.3.1 Overview
Figure 8-5 DRIVE-CLiQ coupling
1 Rating plate
2 Covering caps, Yamaichi, order number: Y-ConAS-24-S
