CU305 Control Units
6.5 Meaning of LEDs
Manual
Manual, 01/2011, 6SL3097-4AC10-0BP2
179
Update
Table 6- 23 Firmware update from memory card
LED
RDY COM OUT>5V MOD
Status Comment
Red Orange OFF OFF Firmware update COM-LED flashing without
specific flashing frequency
Red 2 Hz Red OFF OFF Firmware update
failed
Check whether the memory
card is inserted or replace the
memory card.
Red 0.5 Hz Red 0.5 Hz OFF OFF Firmware update
complete, waiting for
POWER ON
-
Red 2 Hz Red OFF OFF Firmware check
(CRC error)
CRC is incorrect.
Red 2 Hz Red 2 Hz OFF OFF Firmware or memory
card incompatible
Check the firmware version or
memory card.
6.5.2 Behavior of the LEDs in the operating state
Table 6- 24 Control Unit CU305 – description of the LEDs in the operating state
LED Color Status Description/cause Remedy
- OFF Electronic power supply is missing or outside
permissible tolerance range.
Check the power
supply
Continuous The unit is ready for operation.
Cyclic DRIVE-CLiQ communication is in
progress.
-
0.5 Hz flashing
light
Commissioning/reset -
Green
2 Hz flashing
light
Writing to the memory card. -
Red Flashing
2 Hz
General errors Check parameter
assignment/configurati
on.
Red/green Flashing
0.5 Hz
The control unit is ready for operation, but there
are no software licenses.
Install the missing
licenses.
Flashing
0.5 Hz
Updating the firmware of the DRIVE-CLiQ
components.
-
Orange
Flashing
2 Hz
DRIVE-CLiQ component firmware update
completed. Waiting for POWER ON of the
corresponding components.
Switch on the
component.
RDY
(READY)
Green/
orange
or
Red/orange
Flashing
2 Hz
Detection of the component via LED is activated
(p0124[0]).
Note:
Both options depend on the LED status when
module recognition is activated via p0124[0] = 1.
-
