Mains connection and line-side power components
2.9 Line connection variants
Manual
60 Manual, 01/2011, 6SL3097-4AC10-0BP2
2.9.3 Operation of the Line Connection Components via an Autotransformer
An autotransformer can be used to adapt the voltage in the range up to 3-ph. 480 V AC
+10 % or 1-ph. 240 V AC +10 %.
CAUTION
To ensure safe electrical separation, an isolating transformer must be used for voltages
greater than 3-ph. 480 V AC and 1-ph. 240 V AC.
Application example:
● The motor insulation must be protected from excessive voltages.
$XWRWUDQVIRUPHU
)XVHV
RSWLRQDO
/LQHUHDFWRU
/LQHFRQWDFWRU
)XVHV
/LQHILOWHU
LQWH[W
RSWLRQDO
$GGLWLRQDO
ORDGV
///
:98
3RZHU
0RGXOH
1/
:98
3RZHU
0RGXOH
1
1
/
3(
/
/
Figure 2-19 Autotransformer
