System overview
1.4 System data
Manual
26 Manual, 01/2011, 6SL3097-4AC10-0BP2
Biological environmental conditions:
Storage in the transport packaging
Transport in the transport packaging
Operation
Class 1B1 to EN 60721-3-1
Class 2B1 to EN 60721-3-2
Class 3B1 to EN 60721-3-3
Vibratory load
Long-term storage in the transport packaging
Transport in the transport packaging
Operation
Class 1M2 acc. to EN 60721-3-1
Class 2M3 acc. to EN 60721-3-2
Test values: 10 Hz to 58 Hz 0.075 mm; 58 Hz to 200 Hz 1 g
Shock load
Long-term storage in the transport packaging
Transport in the transport packaging
Operation
Class 1M2 acc. to EN 60721-3-1
Class 2M3 acc. to EN 60721-3-2
Test values: 15 g / 11 ms
Climatic ambient conditions
Long-term storage in the transport packaging
Transport in the transport packaging
Operation
Class 1K4 acc. to EN 60721-3-1
Temperature -25 °C to +55 °C
Class 2K4 acc. to EN 60721-3-2
Temperature -40 °C to +70 °C
Class 3K3 acc. to EN 60721-3-3
Temperature +0 °C to +40 °C
Relative humidity 5% to 90%
≤ 60%, in environments which contain corrosive gases and/or dust.
Oil mist, saline fog, ice, condensation, dripping water, spray water, and
splashes or jets of water are not permissible.
Certificates
Declarations of Conformity CE (Low-Voltage and EMC Directive)
Approvals cULus
