CU305 Control Units
6.5 Meaning of LEDs
Manual
178 Manual, 01/2011, 6SL3097-4AC10-0BP2
6.5.1 Behavior of the LEDs during booting
Loading
Table 6- 21 Load software
LED
RDY COM OUT>5V MOD
Status Comment
Orange Orange OFF Red Reset Hardware reset
Red Red OFF OFF BIOS loaded -
Red 2 Hz Red OFF OFF BIOS error Error occurred while loading the
BIOS
Memory card not inserted or
faulty
Red 2 Hz Red 2 Hz OFF OFF File error
Software on memory card not
present or corrupted
Table 6- 22 Firmware
LED
RDY COM OUT>5V MOD
Status Comment
Red Orange OFF OFF Firmware loading COM-LED flashing without
specific flashing frequency
Red OFF OFF OFF Firmware loaded -
OFF Red OFF OFF Firmware check
(no CRC error)
-
Red 0.5 Hz Red 0.5 Hz OFF OFF Firmware check
(CRC error)
CRC is incorrect
Orange OFF OFF OFF Firmware
initialization
-
