Mains connection and line-side power components
2.8 Line reactors
Manual
56 Manual, 01/2011, 6SL3097-4AC10-0BP2
Table 2- 12 Technical specifications, blocksize line reactors, frame sizes FSB and FSC
Line supply voltage 3-ph 380 V AC -10% to 480 V AC +10%
Frame size FSB FSC
Order No. 6SL3203- 0CD21-0AA0 0CD21-4AA0 0CD22-2AA0 0CD23-5AA0
Suitable for
Power Module
6SL3210-
1SE16-0xxx
1SE17-7xxx
1SE21-0xxx 1SE21-8xxx
1SE22-5xxx
1SE23-2xxx
Rated line reactor
current
A 9 11.6 25 31.3
Power loss
50 / 60 Hz
W 9/11 27/32 98/118 37/44
Line supply
connection
U1, V1, W1
Screw-type terminal
6 mm
2
Screw-type terminal
6 mm
2
Screw-type terminal
6 mm
2
Screw-type terminal
6 mm
2
Load connection
1U2, 1V2, 1W2
Cable 4 x 1.5 mm
2
Length approx.
0.46 m
Cable 4 x 1.5 mm
2
Length approx.
0.46 m
Cable 4 x 2.5 mm
2
Length approx.
0.49 m
Cable 4 x 2.5 mm
2
Length approx.
0.49 m
PE connection At the housing with
M5 stud
At the housing with
M5 stud
At the housing with
M5 stud
At the housing with
M5 stud
Degree of protection IP20 or IPXXB IP20 or IPXXB IP20 or IPXXB IP20 or IPXXB
Weight kg 3.4 3.4 6.3 6.4
Table 2- 13 Technical specifications, blocksize line reactors, frame sizes FSD, FSE, and FSF
Line supply voltage 3-ph 380 V AC -10% to 480 V AC +10%
Frame size FSD FSE FSF
Order number 6SL3203-
0CJ24-5AA0
6SL3203-
0CD25-3AA0
6SL3203-
0CJ28-6AA0
6SE6400-
3CC11-2FD0
6SE6400-
3CC11-7FD0
Suitable for
Power Module
6SL3210-
6SL3215-
1SE23-8xxx
1SE24-5xxx
1SE23-8UAx
1SE26-0xxx
1SE26-0UAx
1SE27-5xxx
1SE31-0xxx
1SE27-5UAx
1SE31-0UAx
1SE31-1xxx
1SE31-5xxx
1SE31-1UAx
1SE31-8xxx
1SE31-8UAx
Rated line
reactor current
A 54 71 105 178 225
Power loss
50/60 Hz
W 90/115 90/115 170/215 280/360 280/360
Line supply
connection
U1, V1, W1
Screw-type
terminal
16 mm
2
Screw-type
terminal
16 mm
2
Screw-type
terminal
50 mm
2
Flat connector
for M10 cable
lug
Flat connector for
M10 cable lug
Load
connection
1U2, 1V2, 1W2
Cable
4 x 16 mm
2
Length approx.
0.70 m
Cable
4 x 16 mm
2
Length approx.
0.70 m
Cable
4 x 35 mm
2
Length approx.
0.70 m
Flat connector
for M10 cable
lug
Flat connector for
M10 cable lug
PE connection At the housing with
M8 screw
At the housing with
M8 screw
At the housing with
M8 screw
On housing with
M8 bolt
On housing with
M8 bolt
Degree of
protection
IP20 or IPXXB IP20 or IPXXB IP20 or IPXXB IP00 IP00
Weight kg 13 13 19 25 25
