Cabinet design and EMC for components, Blocksize format
9.5 24 V DC Supply Voltage
Manual
260 Manual, 01/2011, 6SL3097-4AC10-0BP2
9.5.4 Typical 24 V current consumption of the components
A separate 24 V power supply must be used for the SINAMICS S110 drive line-up.
The following table can be used to calculate the 24 V DC power supply. The values for
typical current consumption are used as a basis for configuration.
Table 9- 3 Overview of 24 V DC current consumption
Component Typical current consumption [A
DC
]
Control Units
CU305 PN without load
Per digital output
0.8
0.1
CU305 DP without load
Per digital output
0.8
0.1
CU305 CAN without load
Per digital output
0.8
0.1
DRIVE-CLiQ and brake
DRIVE-CLiQ (e.g. motors with DRIVE-CLiQ interface) Typ. 0.25/Max. 0.45
Brake (e.g. motor holding brake) Typ. 0.4 to 1.1/Max. 2
Sensor Module Cabinet
SMC10
without/with encoder system
0.20 / 0.35
SMC20
without/with encoder system
0.20 / 0.35
SMC30
without/with encoder system
0.20 / 0.55
Sensor Module External
SME20
without/with encoder system
0.15 / 0.25
SME25
without/with encoder system
0.15 / 0.25
SME120
without/with encoder system
0.20 / 0.30
SME125
without/with encoder system
0.20 / 0.30
