Supplementary system components and encoder system integration
7.3 Sensor Module Cabinet-Mounted SMC20
Manual
202 Manual, 01/2011, 6SL3097-4AC10-0BP2
Pin Signal name Technical specifications
19 C Absolute track signal C
20 C* Inverse absolute track signal C
21 D Absolute track signal D
22 D* Inverse absolute track signal D
23 Data* Inverse data, EnDat interface,
Inverse SSI data
24 Ground Ground (for internal shield)
25 - Temp Motor temperature measurement KTY84-1C130 (KTY-)
Temperature sensor KTY84-1C130 / PTC
NOTICE
The KTY temperature sensor must be connected with the correct polarity.
DANGER
Risk of electric shock!
Only temperature sensors that meet the safety isolation specifications contained in
EN 61800-5-1 may be connected to terminals "+Temp" and "-Temp".
If these instructions are not complied with, there is a risk of electric shock!
7.3.3.4 Electronics power supply X524
Table 7- 11 X524 terminal block
Terminal Function Technical specifications
+ Electronic power supply
+ Electronic power supply
M Electronic ground
+
M
M Electronic ground
Voltage: 24 V (20.4 V – 28.8 V)
Current consumption: Max. 0.35 A
Maximum current via jumper in connector: 20 A
Max. connectable cross-section: 2.5 mm²
Type: Screw-type terminal (see Appendix A)
Note
The two "+" or "M" terminals are jumpered in the connector. This ensures that the supply
voltage is looped through.
