Mains connection and line-side power components
2.7 Line filter
Manual
Manual, 01/2011, 6SL3097-4AC10-0BP2
39
2.7.2 Safety information
DANGER
Line filters are only suitable for direct connection to TN systems with grounded neutral
conductor.
WARNING
The cooling clearances of 100 mm above and below the components must be observed.
This prevents thermal overload of the line filter.
WARNING
The connections must not be interchanged:
Incoming line cable to LINE/NETZ L1, L2, L3
Outgoing cable to the line reactor to LOAD/LAST L1', L2', L3'
Non-observance may damage the line filter
CAUTION
Using line filters not released by Siemens AG for SINAMICS can lead to line reactions that
can damage or destroy other loads powered from the network.
