- 39 - BIOS Setup
2-2-2 Trusted Computing
TPM Device
Selects the TPM. Once selected, the dTPM will be disabled and all data saved on it will be lost.
Default setting is dTPM.
Conguration
Security Device Support
Enable/Disable BIOS support for security device. When enabled, OS will not show Security Device. TCG
EFI protocol and INT-1A interface will not be available.
Options available: Enable/Disable. Default setting is Enable.
