1-2 ProductSpecications
CPU
Intel® Xeon® W-2200 and W-2100 Processor Family
Processor TDP up to 165W
1 x LGA 2066
Socket R4
Mounting pitch: square ILM (80x80mm)
Chipset Intel® C422 Express Chipset
Memory 8 x DIMM slots
DDR4 memory module supported only
Quad channel memory architecture
RDIMM modules up to 64GB supported
LRDIMM modules up to 128GB supported
1.2V modules: 2666/2400 MHz
NOTE: When installing memory modules, make sure to begin with the rst socket of
each channel, such as DIMM_P0_A0, DIMM_P0_B0, DIMM_P0_C0, DIMM_P0_D0
Audio Realtek® ALC1150 HD audio codec
Supports 7.1 channel congurations
LAN
2 x GbE LAN ports (Intel® I210)
Expansion Slots Slot_7: 1 x PCIe x16 (Gen3 x16 bus) slot from CPU0
Slot_6: 1 x PCIe x16 (Gen3 x0 or x8 bus) slot
Slot_5: 1 x PCIe x16 (Gen3 x16 or x8 bus) slot, shared with slot_6
Slot_4: 1 x PCIe x16 (Gen3 x0 or x8 bus) slot
Slot_3: 1 x PCIe x16 (Gen3 x16 or x8 bus) slot, shared with slot_4
Slot_2: 1 x PCIe x16 (Gen3 x0 or x8 bus) slot
Slot_1: 1 x PCIe x16 (Gen3 x16 or x8 bus) slot, shared with slot_2
1 x M.2 slot:
- M-key
- PCIe Gen3 x4
- Supports NGFF-2242/2260/2280/22110 cards
Support NVIDIA® SLI™ and AMD® CrossFireX™ technologies
NOTE: Graphic card requests UEFI-ready
Storage Interface 8 x SATA III 6Gb/s ports with 2 x SATA DOM supported
2 x SATA III 6Gb/s ports (Marvell 88SE9172® controller)
RAID Intel® SATA RAID 0/1/10/5
