BIOS Setup - 44 -
CPU FAN Type
Selects the CPU fan type.
Options available: 3 Pins/4 Pins/Auto. Default setting is Auto.
System FAN 1/2/3/4/5 Type
Selects the system fan type.
Options available: 3 Pins/4 Pins/Auto. Default setting is Auto.
Chassis Opened Warning
Enable/Disable a warning message when the system chassis is opened.
Options available: Enabled/Disabled/Clear. Default setting is Disabled.
THRM EXT For FAN 4/5
Selects the THRM EXT function.
This option is disabled by default. For Fan 4, selects TH1 for THRM1 EXT. For Fan 5, selects TH2 for
THRM2 EXT.
Options available: Disabled/THRM1/THRM2. Default setting is Disabled.
CPU Temperature
Displays the current CPU fan temperature.
System Temperature
Displays the current system fan temperature.
CPU Fan Speed
Displays the current CPU fan speed (RPM).
System Fan 1/2/3/4/5 Speed
Displays the current system fan speed (RPM).
