- 57 - BIOS Setup
Key Exchange Keys (KEK)
Displays the current status of the Key Exchange Key Database (KEK).
Press [Enter] to enroll a new KEK or load additional KEK from storage devices.
Options available: Update/Append.
Authorized Signatures (DB)
Displays the current status of the Authorized Signature Database.
Press [Enter] to enroll a new DB or load additional DB from storage devices.
Options available: Update/Append.
Forbidden Signatures (DBX)
Displays the current status of the Forbidden Signature Database.
Press [Enter] to enroll a new dbx or load additional dbx from storage devices.
Options available: Update/Append.
Authorized TimeStamps (DBT)
Displays the current status of the Authorized TimeStamps Database.
Press [Enter] to enroll a new DBT or load additional DBT from storage devices.
Options available: Update/Append.
OsRecovery Signatures
Displays the current status of the OsRecovery Signature Database.
Press [Enter] to enroll a new OsRecovery Signature or load additional OsRecovery Signature from
storage devices.
Options available: Update/Append.
