Commissioning Manual EM11A021

DCM601A51 intelligent Touch Manager

(44) Upper Limit eld

Sets up the upper limit and monitoring status for upper limit error monitoring.

For the upper limit, touch the Modify button and enter it in the Numerical Input dialog that

appears.

For the monitoring status, select from Disable, Monitoring, and Monitor + History from the combo

box.

(45) Analog Type radio button

Select the analog value type from Temperature and Other.

(46) Unit Type radio button

Select the unit type of External Ai either “Thermistor” or “Other”. The unit type cannot be

congured when Other is selected in Analog Type (45).

Selecting Thermistor sets the Minimum value and Maximum value text elds (47) to –512.0 and

512.0 (or –890 and 954 in Fahrenheit), respectively, which cannot be changed.

(47) Minimum Value / Maximum Value text eld

Sets up the physical quantities corresponding to the minimum and maximum analog value input

signals.

Touch the Modify button and enter the value in the Numerical Input dialog that appears.

(48) Reference settings eld

Sets up the Target Point and Target analog value for the Internal Ai.

Touch the Ref.. button and select the Target Point and Target analog value to set from the Analog

Point Selection screen that appears (see page 32).
