Commissioning Manual EM11A021
DCM601A51 intelligent Touch Manager
23
The range of values you can enter/set is as indicated in the table below.
Detailed
Type
Port number Address
View
Minimum/Maximum value
(Default value)
View
Minimum/Maximum value
(Default value)
Non-differentiated
Di/Pi 1 to 8 (1)* 1 to 4 (2)*
D3Di
1 to 8 (1) 1-00 to 4-15 (1-00)
D3Dio
1 to 8 (1) 1-00 to 4-15 (1-00)
Indoor unit
1 to 8 (1) 1-00 to 4-15 (1-00)
Ventilator
1 to 8 (1) 1-00 to 4-15 (1-00)
D3Chiller
1 to 8 (1) 1-00 to 4-15 (1-00)
Outdoor unit
1 to 8 (1) × -
Internal Ai × - × -
Internal Pi
1 to 8 (1) × -
* The combination: Port number 1 and Address 1 is assigned exclusively
for the input of the iTM unit emergency stop signal and cannot be used.
(16) Detailed Type eld
Displays the detailed management point type. However, you cannot modify it here.
(17) Mgmt. Pt. ID eld
Displays the management point ID automatically allocated by the system. However, you cannot
modify it here.
(18) Name text eld
Sets up the management point name.
Touch the Modify button and enter the name in the Name Input dialog that appears.
Specify a name for the management point using 1 to 12 characters, irrespective of single or
double byte.
(19) Detailed Info. text eld
Set up information about the management point as necessary.
Touch the Modify button and enter the value in the Text Input dialog that appears.
The number of characters you can enter is 0 to 50, irrespective of single or double byte.
(20) Icon eld
Sets up the icon for the management point.
Touch the Modify button and set the icon in the Icon Setup screen that appears.
