Commissioning Manual EM11A021
DCM601A51 intelligent Touch Manager
77
Outputting the Leakage Check results to a CSV le
Output the Leakage Check results to a CSV le.
(19)
(20)
1. Insert a USB memory into the iTM and touch the CSV Output button (20). A conrmation dialog
appears. Touching the Yes button outputs to the USB memory the Leakage Check results for all
outdoor units registered in the Outdoor Unit list (19) as a CSV le named LeakageCheck.csv. If
a le with the same name already exists, the Leakage Check results are saved by naming the
le LeakageCheck+sequential number (1 to 9). If there are no more sequential numbers that can
be used, an error dialog is displayed and the output to CSV le aborted.
When operation is via Web connection, the CSV is output to the HDD of the PC connected
to the Web.
NOTE
The CSV le format specication is as follows.
Controller name
Date, Time
Version number
Title
Check Date/
Leakage Amount
Leakage AmountCheck DateLeakage AmountCheck DateLeakage AmountCheck Date
b
zyx
.. ..
Outdoor 80Outdoor 2Outdoor 1
Up to 160 columns
intelligent Touch
Manager
2010/11/17 PM 2:00
Ver 1.00.00
Leakage Check
Result
. . .
. . .
. . .
. . .
. . .
. . .
. . .
2010/5/10
AM1:00
2010/11/10
AM2:00
a
2010/5/23
AM2:30
2010/11/10
AM2:00
2010/5/10
AM1:00
