Commissioning Manual EM11A021

DCM601A51 intelligent Touch Manager

4-6 History Mgmt. (Delete)

Deletes history records.

1. Log into SE Mode from the Menu List screen and display the Service Settings tab (see page 7).

Touch the History Mgmt. button on the Service Settings tab to display the History Management

screen (see page 10).

(1)

(2) (3)

(6)

(5)(4)

2. Using the Remove history data radio button (1), select whether to delete All or a Period.

3. If you selected Period, set up the start date of the period to delete in (2) and the end date in (3).

To set up the start date, touch the Modify button (4) and enter the start date in the Time Input

dialog box that appears. Touch the OK button to commit the start date and close the dialog. The

start date is displayed in the From eld (2). To set the end date, touch the Modify button (5) and

enter the end date in the Time Input dialog box that appears. Touch the OK button to commit the

end date and close the dialog. The end date is displayed in the To eld (3).

4. Touching the Delete button (6) displays a conrmation dialog. Touch the Yes button to delete the

history for the specied period. Touch the Close button and close the screen.

If you specified a period to delete, you can cancel deletion halfway but the history data

before cancelling will be deleted. Make sure before executing because the deleted data

cannot be recovered.

NOTE
