Commissioning Manual EM11A021
DCM601A51 intelligent Touch Manager
81
Failure mode
The following describes the failure modes of the Leakage Check.
Scene Failure mode Impact to users Cause
Handling
Notication method
Recovery method
When How
Preparation
Forget to run
Refrigerant
Charging
Operation
Cannot run Leakage
Check
Cannot recognize the
amount of
automatically
charged
refrigerant
When the
[Check Start]
button is
touched
• An error message
indicating No Auto
Charge is displayed
• No Auto Charge is
recorded in the
history
Touch the [Check
Start] button after
running Refrigerant
Charging Operation
At schedule
trigger
• No Auto Charge is
recorded in the
history
Set up the schedule
again after running
Refrigerant Charging
Operation
Forgot the
outdoor unit
address
Cannot conduct
Leakage Check
A check command
cannot be sent
because the outdoor
unit address of the
command destination
is unknown
When [Check
Start] is
pressed
• The message of
communication
error is displayed
• The history of
communication
errors is saved
Press [Check Start]
again after setting
the outdoor unit
address
At schedule
trigger
• The history of
communication
errors is saved
Set the schedule
again after setting
the outdoor unit
address
Pre-
engineering
Forget to
register
indoor units
• Possibility of
malfunction since
Automatic Control
is not disabled
• Incorrect Leakage
Check results
Indoor units in the
refrigeration system
are not placed under
maintenance
because refrigeration
system information
for the outdoor unit/
indoor units is
unknown
During
Leakage
Check
• Indoor unit
management point’s
icon (the target
indoor unit’s icon do
not go on)
* Make the operating
procedure include a
step that checks
whether the target
indoor unit’s icon go
on after Leakage
Check is started
Touch the [Check
Stop] button and
stop the Leakage
Check. Register the
indoor units and
touch the [Check
Start] button again,
or set up the
schedule again
Indoor unit
registration
is incorrect
• Possibility of
malfunction since
Automatic Control
is not disabled
• Other than the
target indoor units
are placed under
maintenance and
Automatic Control
on them, disabled
• Incorrect Leakage
Check results
Since the
refrigeration system
information for the
outdoor unit/indoor
units is incorrect, the
indoor units of the
target refrigeration
system are not
placed under
maintenance, or
other than the target
indoor units are
placed under
maintenance
During
Leakage
Check
• Indoor unit
management points’
icon
* Make the operating
procedure include a
step that checks
whether the target
indoor unit’s icon go
on after Leakage
Check is started
Touch the [Check
Stop] button and
stop the Leakage
Check. Modify the
indoor unit
registration and
touch the [Check
Start] button again,
or set up the
schedule again
Schedule
setup
Set up an
overlapping
program
None — Only the program with the smallest number will be executed
