Commissioning Manual EM11A021

DCM601A51 intelligent Touch Manager

4. Click the Edit Data button (13) to start up the iTM demo version for PC.

The steps from editing using the demo version for PC to restore data output to USB and iTM

restore are the same as steps 3 to 5 of the procedure for Scenario 1: Installation to new property.

The Layout Setup data backup and restore procedures are the same as when modifying the

Layout View of an existing property. For the method of editing the Layout Setup data, see the

supplementary volume Layout View Creation Tool (optional).

NOTE
