Commissioning Manual EM11A021
DCM601A51 intelligent Touch Manager
73
2. The management point name of the target outdoor unit appears in the Name eld (7).
You may set up to four schedule programs per outdoor unit.
Enable/disable the schedule program in (8).
Set up the Leakage Check start date in (9). Touch the Modify button and enter the time in the
Time Input dialog that appears. The range of values you can specify is January 1, 2010 to
December 31, 2036.
(10) displays the start time. Touch the Modify button and enter the time in the Time Input dialog
that appears. The range of values you can specify is “00:00 to 23:59 (AM12:00 to PM11:59 when
12-hour clock is used)”. Click the OK button to commit the program and close the screen.
• Date and time are displayed according to the locale settings.
• For duplicated execution times, the program with the smaller number has precedence.
• When the system time is adjusted for clock drift, the execution of a scheduled Leakage
Check changes as follows for an adjustment that stretches over the program execution
time, depending on the extent of the adjustment.
Condition Extent of adjustment
Operation when execution time falls within
the adjustment
When time is advanced
Fine adjustment
(Up to +120 sec)
Executed immediately after the time is
modied
Signicant adjustment
(+120 sec or more)
Not executed
When time is put back
Fine adjustment
(Up to −120 sec)
Not executed
Signicant adjustment
(−120 sec or more)
Executed at the specied time (duplicated
execution)
• On DST start date, a time gap results while on the end date, a duplicated period of time
results.
If a scheduled program’s execution time falls within these periods of time, it operates as
follows.
Set to the time gap on DST start date
→
Not executed (The specied time does not occur)
Set to the duplicated period of time on DST end date
→
Executed twice (The specied
time occurs twice)
NOTE
