User’s Manual of IGS-801M
The
configable filelds includes the following items:
Object Description
VID
The VLAN ID attached to the MAC Address.
Ports
Specifies the port numbers for which the table is queried.
MAC-Address
Input the MAC address entry be manualed bind to the specify port.
The MAC Address Table includes the following fields:
Object Description
VID
The VLAN ID attached to the MAC Address.
Ports
Specifies the port numbers for which the table is queried.
Type Static - Static addresses are manually configured. Packets received with the
dest be forward to the
specify port.
inated MAC address mathch the port static MAC setting will
MAC-Address
The MAC address listed in the current static address list.
