User’s Manual of IGS-801M

4.2.11 Green Networking

This page is used to enable/disable green networking function. Enable Power Saving mode will reduce system power

consumption when the link is not present.

Figure 4-2-16 Green Ethernet screenshot

he page includes the following fields: T

Object Description

Power Saving

Enable mode will reduce chip power when the signal from the copper link partner

is not present.

4.2.12 Logout

Press this function; the web interface will go back to login screen. The screen in Figure 4-67 and Figure 4-2-17 appears.

Figure 4-2-17 Logout screen
