User’s Manual of IGS-801M
4.8.4 DSCP QoS Mode
DiffSer (DSCP) － on bits within an IP header that are encoded by certain
applica s to in
The DSCP Configuration
Select the QoS mode to DSCP ue mapping configuration page appears, as the Figure 4-8-5 shows.
v Code Point is the traffic prioritizati
tions and/or device dicate the level of service required by the packet across a network.
page provides fields for defining output queue to specific DSCP fields.
, the DSCP to que
Figure 4-8-5 DSCP QoS Configuration screen
The page includes the following fields:
Object Description
Prioritize Traffic
The draw menu allows customization of DSCP to Traffic classifiers. Total 5
selections for the Prioritize Traffic.
• Custom – Manual mapping the DSCP to the 4-level queues. Setup at the
next table.
• All Low Priority - mapping all IP DCSP header packets to Queue 0
93
