![Planet IGS-801T [8/120] Product specification](/views2/1071788/page8/bg8.png)
User’s Manual of IGS-801M
•
IEEE802.1w Rapid Spanning Tree Protocol
¾ Quality of Service
4 priority queues on all switch ports
Traffic classification:
•
IEEE 802.1p CoS
•
IP TOS / DSCP
Strict priority and Weighted Round Robin (WRR) CoS policies
¾ Multicast
IGMP Snooping v1 and v2
IGMP Query mode for Multicast Media application
¾ Security
IEEE 802.1x Port-Based Authentication
Port Mirroring to monitor the incoming or outgoing traffic on a particular port
¾ Management
Remote WEB-based management
Access through SNMP v1, v2c
SNMP Trap for alarm notification of events
Firmware upgrade through web interface
Cable Diagnostics technology
Supports PLANET Smart-DISCOVERY Utility for deploy management
¾ Industrial Case / Installation
IP-30 Aluminum case protection
DIN Rail and Wall Mount Design
Redundant Power Design
12 to 48V DC, redundant power with polarity reverse protect function
Supports EFT protection 6000 VDC for power line
Supports 6000 VDC Ethernet ESD protection
-10 to 60 Degree C operation temperature
1.4 Product Specification
Product IGS-801M
Hardware Specification
Copper Ports 8 10/ 100/1000Base-T RJ-45 Auto-MDI/MDI-X ports
Switch Processing Scheme Store-and-Forward
Switch Fabric 16Gbps
Throughput (packet per second) 11.9Mpps
Address Table 8K entries
Share Data Buffer 176 kilobytes on-chip frame buffer
8
