User’s Manual of IGS-801M
Subnet Mask The IP subnet mask for the interface. The factory default value is 255.255.255.0
Gateway
The default gateway for the IP interface. The factory default value is 192.168.0.1.
Management VLAN
Specifies the management VLAN ID of the switch. It may be configured to any
value in the range of 1 - 4093. The management VLAN is used for management
of the switch.
The factory default management VLAN is “VLAN 1”.
Defines the user-defined device name.
System Description
Inactivity Timeout
eriod for the user login. The web interface will be auto logout if
there’re no actions from the login user.
The default value is 300 seconds; 0 means no inactivity time limit.
Specifies a time p
4.2.3 User Authentication
This page allows you to configure the system password required to access the web pages. After setup completed, please
press “Apply” button to take effect. Please login web interface with new password, the screen in Figure 4-2-3 appears.
Figure 4-2-3 User Authentication page screenshot
The page includes the following fields:
Object Description
Password The system password. The allowed string length is 1 to 16, and the allowed
content is the ASCII characters from 32 to 126. It will not display as it is typed,
onl e alpha numeric characters in length,
and are case sensitive.
y asterisks (*) will show. Passwords ar
After change the ord, if you forget the password. Please press the “Reset” button
in the front panel of the Managed Switch over 10 seconds and then release, the current setting
AN,
default passw
includes VL will be lost and the Managed Switch will restore to the default mode.
