User’s Manual of IGS-801M
Port-1 to Port-8 10/100/1000Base-T
LED Color Function
Lit:
Indicate the port is successfully connecting to the network at
1000Mbps
Blinking:
Indicate that the port is actively sending or receiving data over
that port.
1000 Green
Off:
Indicate that no device attached or it is successfully
connecting to the network at 10Mbps or 100Mbps.
Lit:
Indicate the port is successfully connecting to the network at
100Mbps or 10Mbps.
Blinking:
Indicate that the port is actively sending or receiving data over
that port.
100 Green
Off:
Indicate that no device attached or it is successfully
connecting to the network at 1000Mbps.
