User’s Manual of IGS-801M
2.2 Install the Switch
This section describes how to install your Managed Industrial Switch and make connections to the Managed Industrial
Switch. Please read the following topics and perform the procedures in the order being presented. To install your switch on
a desktop or shelf, simply complete the following steps.
In this paragraph, we will describe how to install the 8 10/100TX w/ X-Ring Managed Industrial Switch and the installation
points attended to it.
2.2.1 Installation Steps
1. Unpack the Industrial switch
2. Check if the DIN-Rail is screwed on the Industrial switch or not. If the DIN-Rail is not screwed on the Industrial
switch, please refer to DIN-Rail Mounting section for DIN-Rail installation. If users want to wall mount the Industrial
switch, please refer to Wall Mount Plate Mounting section for wall mount plate installation.
3. To hang the Industrial switch on the DIN-Rail track or wall.
4. Power on the Industrial switch. Please refer to the Wiring the Power Inputs section for knowing the information
about how to wire the power. The power LED on the Industrial switch will light up. Please refer to the LED
Indicators section for indication of LED lights.
5. Prepare the twisted-pair, straight through Category 5 cable for Ethernet connection.
6. Insert one side of RJ-45 cable (category 5) into the Industrial switch Ethernet port (RJ-45 port) and another side
of RJ-45 cable (category 5) to the network device’s Ethernet port (RJ-45 port), ex: Switch PC or Server. The UTP
port (RJ-45) LED on the Industrial switch will light up when the cable is connected with the network device. Please
refer to the LED Indicators section for LED light indication.
Make sure that the connected network devices support MDI/MDI-X. If it does not support,
use the crossover category-5 cable.
7. When all connections are set and LED lights all show in normal, the installation is complete.
2.2.2 DIN-Rail mounting
The DIN-Rail is screwed on the Industrial Gigabit Ethernet Switch when out of factory. When need to replace the wall
mount application with DIN-Rail application on Industrial Gigabit Ethernet, please refer to following figures to screw the
DIN-Rail on the Industrial Gigabit Ethernet Switch. To hang the Industrial Gigabit Ethernet Switch, follow the below steps:
15
