User’s Manual of IGS-801M
2.1.4 Bottom View
At the bottom of the IGS-801M, the RESET button is designed for reboot the Managed Industrial Switch without turn off
and on the power.
RESET
Figure 2-4 Bottom Panel of IGS-801M
The following is the summary table of Reset button functions:
Reset Button Pressed and Released Function
About 1~3 second Reboot the Managed Industrial Switch
Until the PWR LED lit off
Reset the Managed Industrial Switch to Factory Default
configuration. The Managed Industrial Switch will then reboot
and load the default settings as below:
。 Default Password: admin
。 Default IP address: 192.168.0.100
。 Subnet mask: 255.255.255.0
。 Default Gateway: 192.168.0.254
2.1.5 LED Indicators
The diagnostic LEDs that provide real-time information of system and optional status are located on the front panel of the
IGS-801M. The following table provides the description of the LED status and their meanings for the Managed Industrial
Switch.
System
LED Color Function
Lit: Power 1 is active
P1 Green
Off: Power 1 is inactive
Lit: Power 2 is active
P2 Green
Off: Power 2 is inactive
Lit: Indicate the either Power 1 or Power 2 has no power
FAULT Green
Off: No failure
13
