User’s Manual of IGS-801M
Flow Control
IEEE 802.3x Pause Frame for Full-Duplex
Back pressure for Half-Duplex
Jumbo Frame 9Kbytes
LED
System:
Power 1, Power 2, Fault Alarm
Ports:
10/100 Link/Act
1000 Link/Act
Installation DIN rail kit and wall mount ear
Power Supply
External Power Supply: DC 12~48V
Redundant power DC 12~48V and connective removable terminal
block for master and slave power
Power Consumption
8.2 Watts (Full load)
Operating Temperature
Standard: -10 Degree C ~ 60 Degree C
Operating Humidity
5% to 95% (Non-condensing)
Storage Temperature
-40 Degree C ~ 85 Degree C
Case Dimension
IP-30, 135mm x 87mm x 32mm (W x D x H)
Weight
473g
Layer 2 Function
System Configuration Web Browser, SNMPv1, v2c monitor, SNMP Trap
Port configuration
Port disable/enable.
Auto-negotiation 10/100/1000Mbps full and half duplex mode selection.
Flow Control disable / enable.
VLAN
802.1Q Tagged Based VLAN ,up to 64 VLAN groups
Port-Based VLAN, up to 8 VLAN groups
Port trunking
IEEE 802.3ad LACP / Static Trunk
Support 4 groups of 8-Port trunk support
QoS
Traffic classification based, Strict priority and WRR
4-level priority for switching
- 802.1p priority
- DSCP/TOS field in IP Packet
IGMP Snooping
IGMP (v1/v2) Snooping, up to 256 multicast Groups
IGMP Querier mode support
Storm Control
• Broadcast storm control
• Multicast storm control
• Flooded Unicast storm control
SNMP MIBs
RFC-1213 MIB-II
IF-MIB
RFC-1493 Bridge MIB
RFC-2863 Interface MIB
Q-Bridge MIB
9
