User’s Manual of IGS-801M
Drop frames after
excessive collisions
Enab
det
le or Disable the device to drop frames once the excessive collisions be
ected.
Port
Indicate port 1 to port 8.
Mode
Allow configuring the port speed and operation mode. Draw the menu bar to
10 half - Force sets 10Mbps/Half-Duplex mode.
• 10 Full - Force sets 10Mbps/Full-Duplex mode.
• 100 half - Force sets 100Mbps/Half-Duplex mode.
• 100 full - Force sets 100Mbps/Full-Duplex mode.
• 1000 full - Force sets 10000Mbps/Full-Duplex mode.
• Disable - Shutdown the port manually.
select the mode.
• Auto Speed - Setup Auto negotiation.
•
Flow Control Allow Enable or Disable flow control for selected port.
• Enable – 802.3x flow control is enabled on Full-Duplex mode or
Backpressure is enabled on Half-Duplex mode.
• Disable – No flow control or backpressure function on no matter
Full-Duplex or Half-Duplex mode.
Port Description
Can key in the description for the port.
When set each port to run at 100M Full, 100M Half, 10M Full, and 10M Half-speed modes. The
Auto-MDIX function will disable.
4.3.2 Port Statistics
The Port Statistic page displays the status of packet count from each port. The Port statistics screen in Figure 4-3-2
appears.
39
