User’s Manual of IGS-801M

• All Normal Priority - mapping all IP DCSP header packets to Queue 1

l Medium Priority - mapping all IP DCSP header packets to Queue 2

• All High Priority - mapping all IP DCSP header packets to Queue 3

• Al

DSCP Value ( 0..63)

The values of the IP DSCP header field within the incoming packet.

Priority

The traffic forwarding queue to which the DSCP is mapped. Four traffic priority

The queue to which packets with the specific DSCP value is assigned. The

values are low,Normal,Medium and High.

• Low = Queue 0

• Normal = Queue 1

• Medium = Queue 2

• High = Queue 3

queues are supported.
