Planet IGS-801T [35/120] Figure 4 2 15 fault relay alarm interface

User’s Manual of IGS-801M

Figure 4-2-14 Ping Result screen

Be sure the target IP Address is within the same network subnet of the switch, or you had setup the

correct gateway IP address.

4.2.10 Fault Relay Alarm

The Fault Relay Alarm function provides the Power Failure detection. With both power input 1 and power input 2 installed

and the check boxes of power 1/power 2 ticked, the FAULT LED indicator will then be possible to light up when any one of

the power failures occurs.

Figure 4-2-15 Fault Relay Alarm interface

The page includes the following fields:

Object Description

Power Failure:

Tick the check box to enable the function of lighting up the FAULT LED on the

panel when power fails.
