ENGLISH
30
This section describes problems and
malfunctions which you should be able
to resolve yourself. If the measures de-
scribed here do not solve your problem,
see 'Repairs'.
ADanger!
Many accidents happen particularly in
connection with problems and faults.
Therefore please note:
• Always unplug before troubleshoo-
ting.
• Check that all safety devices are
operational again after each fault
service.
Motor does not run
No mains voltage
• check cables, plug, outlet and
mains fuse.
No crosscut function
Transport lock activated:
• Deactivate the transport lock.
Safety lock engaged:
• Release safety lock.
Sawing performance too low
Saw blade blunt (possibly tempering
marks on blade body):
Saw blade not suitable for material
being cut (see section 'Technical Da
-
ta');
Saw blade warped:
• Replace saw blade (see section
'Maintenance').
Saw vibrates heavily
Saw blade warped:
• Replace saw blade (see section
'Maintenance').
Saw blade incorrectly mounted:
• Remove the saw blade and then
mount it again correctly (see chap-
ter "Care and Maintenance").
Saw squeaks during start-up
Drive belt tension too low:
• Tighten the drive belt (see section
'Maintenance - Drive belt tensio
-
ning').
Rotary table stiff
Sawdust build-up under rotary table:
• Remove saw dust.
13. Trouble Shooting
14. Technical Data
KS 254 Plus KS 305 Plus
Voltage V 220–240
(1~ 50 Hz)
220–240
(1~ 50 Hz)
110–120
(1~ 60 Hz) (1~ 50 Hz)
Current draw A 8.7 9.4 15 –
Fuse protection A 10 (time-lag) 10 (time-lag) 16 (time-lag)
Motor output (S6 20 % 5 min *) kW 1.8 2.0 – –
Protection class IP 20 20 20
Degree of protection II II II
Saw blade speed min
-1
4700 4100 4100 –
Cutting speed m/s 62 65 65 –
Saw blade diameter (outer) mm 254 305 305
Arbor bore mm 30 30 1“ 30
Dimensions
Machine in packaging (length × width × height)
Machine ready for operation, rotary table in 90° position
(length × width × height)
mm
mm
630 × 575 × 520
723 × 684 × 580
630 × 575 × 520
725 × 758 × 650
630 × 575 × 520
725 × 758 × 650
Maximum workpiece cross section:
Standard cross cuts (width / height)
Mitre cuts (rotary table 45°) (width / height)
Bevel cuts (track arm holder 45° left) (width / height)
Compound mitre cuts (rotary table 45° / track arm holder
45° left) (width / height)
mm
mm
mm
mm
145 / 60
100 / 60
145 / 30
100 / 30
200 / 77
140 / 77
200 / 35
140 / 35
200 / 77
140 / 77
200 / 35
140 / 35
Weight
Machine in packing
Machine ready to work
kg
kg
25
18
26
19
26
19
Permissible temperature for transport and storage °C 0 to +40 0 to +40 0 to +40
