7. How to select tightening torque and rotational speed

CAUTION:

 The selection examples shown in Table 6 should be

considered as general standard. As different types of

tightening screws and different materials to be

tightened are used in actual works proper adjustments

are naturally necessary.

 When using the impact driver drill with a machine

screw at HIGH (high speed), a screw may damage or

a bit may loose due to the tightning torque is too

strong. Use the impact driver drill at LOW (low speed)

when using a machine screw.

NOTE:

 The use of the battery in a cold condition (below 0

degree Centigrade) can sometimes result in the

weakened tightening torque and reduced amount of

work. This, however, is a temporary phenomenon,

and returns to normal when the battery warms up.

8. Using the hook

The hook is used to hang up the power tool to your

waist belt while working.

CAUTION:

 When using the hook, hang up the power tool firmly

not to drop accidentally.

If the power tool is dropped, it may lead to an accident.

 When carrying the power tool with hooked to your

waist belt, do not fit any bit to the tip of power tool. If

the sharp bit such as drill is fitted to the power tool

when carrying it with hooked to your waist belt, you

will be injured.

 Install securely the hook. Unless the hook is securely

installed, it may cause an injury while using.

(1) Removing the hook.

Remove the screws fixing the hook with screw driver.

(Fig. 10)

(2) Replacing the hook and tightening the screws.

Install securely the hook in the groove of power tool

and tighten the screws to fix the hook firmly. (Fig. 11)

9. About Remaining Battery Indicator

When pressing the remaining battery indicator switch,

the remaining battery indicator lamp lights and the

battery remaining power can be checked. (Fig. 12)

When releasing your finger from the remaining

battery indicator switch, the remaining battery

indicator lamp goes off. The Table 7 shows the state

of remaining battery indicator lamp and the battery

remaining power.

As the remaining battery indicator shows somewhat

differently depending on ambient temperature and

battery characteristics, read it as a reference.

NOTE:

 Do not give a strong shock to the switch panel or

break it. It may lead to a trouble.

 To save the battery power consumption, the

remaining battery indicator lamp lights while pressing

the remaining battery indicator switch.

10. How to use the LED light

Every time you press the light switch on the switch

panel, the LED light lights or goes off. (Fig. 13)

To prevent the battery power consumption, turn off

the LED light frequently.

CAUTION:

 Do not expose directly your eye to the light by looking

into the light.

If your eye is continuously exposed to the light, your

eye will be hurt.

State of lamp Battery Remaining Power

The battery remaining power

is enough.

The battery remaining power

is a half.

The battery remaining power

is nearly empty.

Re-charge the battery soonest

possible.

Table 7

Table 6

Use

Clutch dial Position

Rotating speed selection (Position of the shift knob)

LOW (Low speed) HIGH (High speed)

Machine screw 1 – 22

For 4 mm or smaller

diameter screws.

Driving

Wood screw 1 –

For 8 mm or smaller nominal

diameter screws.

Brick

For 14 mm or smaller

diameters. (DV14DBL)

For 16 mm or smaller

diameters. (DV18DBL)

Drilling

Wood

For 50 mm or smaller

diameters. (DV14DBL)

For 65 mm or smaller

diameters. (DV18DBL)

Metal

For drilling with a metal

working drill bit.

For 6 mm or smaller

diameter screws.

For 4.8 mm or smaller

nominal diameter screws.

For 10 mm or smaller

diameters. (DV14DBL)

For 12 mm or smaller

diameters. (DV18DBL)

For 24 mm or smaller

diameters. (DV14DBL)

For 27 mm or smaller

diameters. (DV18DBL)
