English
9
CAUTION
1. If liquid leaking from the battery gets into your
eyes, do not rub your eyes and wash them well
with fresh clean water such as tap water and
contact a doctor immediately.
If left untreated, the liquid may cause eye-problems.
2. If liquid leaks onto your skin or clothes, wash well
with clean water such as tap water immediately.
There is a possibility that this can cause skin irritation.
3. If you find rust, foul odor, overheating, discolor,
deformation, and/or other irregularities when using
the battery for the first time, do not use and return
it to your supplier or vendor.
WARNING
If an electrically conductive foreign object enters the
terminals of the lithium ion battery, a short-circuit may
occur resulting in the risk of fire. Please observe the
following matters when storing the battery.
䡬 Do not place electrically conductive cuttings, nails,
steel wire, copper wire or other wire in the storage
case.
䡬 Either install the battery in the power tool or
store by securely pressing into the battery cover
until the ventilation holes are concealed to prevent
short-circuits (See Fig. 1).
SPECIFICATIONS
POWER TOOL
Model WM14DBL WM18DBL
Electronic pulse mode Wood screw
ø 4.2 × 75
Bolt mode
Ordinary bolt M4 – M10
High tension bolt
M4 – M6
Self
drilling
screw
mode
Self
drilling
screw
ø 6
Capacity
Woodwork drilling
ø 21
Drill mode Steel drilling ø 10
Mortar drilling ø 6
Electronic
clutch
mode
Small screw M6
Maximum 30 N·m Maximum 33 N·m
Bolt mode
{306 kgf·cm} {337 kgf·cm}
Tightening torque [
Tightening time: 3 sec.
] Tightening is M10 high tension bolt
[when
fully
charged (strength grade 12.9) Hexagon socket used
at 20°C temp]
Drill mode 11 N·m {112 kgf·cm}
Electronic clutch mode 5-point clutch 2.3 – 5.3 N·m {23 – 54 kgf·cm}
Edge shape Width across flat 6.35, bit insertion shape
Motor DC motor
Electronic pulse mode 0 – 1100 min
-1
No-load speed
Bolt mode 0 – 640 min
-1
[when
fully
charged
Self drilling screw mode
0 – 1100 min
-1
at 20°C temp]
Drill mode 0 – 1100 min
-1
Electronic clutch mode 0 – 450 min
-1
Number of blows
Electronic pulse mode 0 – 1090 min
-1
[when
fully
charged Bolt mode 0 – 700 min
-1
at 20°C temp]
Self drilling screw mode
0 – 1090 min
-1
Rechargeable battery
BSL1430: Li-ion 14.4 V BSL1830: Li-ion 18 V
(3.0 Ah, 8 cells) (3.0 Ah, 10 cells)
Dimensions of the tool
162 mm × 250 mm × 31 mm 162 mm × 252 mm × 31 mm
Entire length × height × center height (BSL1430 attached) (BSL1830 attached)
Weight
1.5 kg (BSL1430 attached) 1.7 kg (BSL1830 attached)
LED light White LED
Remaining battery indicator lamp Red LED
CHARGER
Model UC18YRSL
Charging voltage 14.4 V 18 V
Weight 0.6 kg
01Eng_WM14DBL_ EE 9/27/10, 9:049
