English O Drill bit A drill with hexagonal shank can be attached directly to the tool To attach a drill without hexagonal shank you need to have the drill chuck adapter set sold separately 1 Insert the drill bit into the chuck 2 Use the chuck key to secure the drill bit tightening the chuck by each of the three holes in tum Fig 11 Use an iron drill to make a pilot hole for a wood screw or a 10 mm or smaller hole 1 Insert the drill bit into the chuck 2 Use the chuck key to secure the drill bit tightening the chuck by each of the three holes in tum Fig 11 HOW TO USE 1 Mode selection function WARNING Use this tool with the mode selection dial set to the correct position it should be clicked and locked in place Ignoring this may cause an unexpected behavior of the tool and result in breaking materials screws or injury CAUTION Do not apply strong impact to the mode selection dial The operation mode can be changed by turning the mode selection dial on the tool and aligning it with the triangular mark The operation mode can be selected from five different modes described in the below table NOTE O The tightening torque obtained by each mode varies according to the screw and material being screwed Adjust the mode selection dial after test tightening a few screws O Use the bolt mode to tighten bolts O Turning the mode selection dial with the tool switched on does not change the mode Switch off the tool before changing the operation mode Example of mode selection Operation mode Marking Mamin tx Application 3 Electronic pulse mode T 2 Wood screw tightening 1 Bolt mode Self drilling screw mode Drill mode T 1 33 N m 2 1 Electronic clutch mode 11 Nm 5 5 3 N m 4 Î Tightening of 50 75 mm screw Tightening screw shorter than 50 mm 30 N m Î 1 Bolt tightening Self drilling screw tightening 05 or 06 Self drilling screw tightening 03 5 or o4 2 Drilling 3 3 Machine screw M6 or tapping screw tightening 2 Gypsum board fixing 1 Notes Diagonal tightening of 75 mm screw O Use the bit and socket which are suitable for the screw diameter O When using the drill mode oe sure not to stop the motor rotation 2 3 N m 1 WM14DBL 30 N m WM18DBL 33 N m 2 Before fixing a thin plate with a self drilling screw make sure that the thickness of the plate is suitable for the screw diameter 3 With the electronic clutch mode 4 or 5 the tool may execute reverse rotation briefly when the load increases in order to reduce a risk of screw head damage 2 Characteristics of Electronic Pulse Driver Unlike a conventional impact driver the electronic pulse driver generates the striking force by rotating the motor in regular and reverse directions repeatedly This mechanism has helped to provide quieter operation The following characteristics are uncommon to a conventional impact driver however these are not signs of malfunction O The tool tends to be heated by continuous screw tightening To protect the motor and electronic parts that control the motor operation this tool is equipped with a temperature protection circuit Depending on the screw and material being screwed the striking operation may start early Since the striking operation causes temperature increase of the motor and electronic parts the temperature protection circuit may be activated early Refer to 1 Continuous operation on page 14 for recovering from the operation stop caused by the temperature protection circuit Also the electronic pulse driver controls the motor rotation consistently to provide the optimum operation for each mode Because of this the following cases can occur during operation O The behavior at operation start differs by the mode The self drilling screw mode 1 gradually increases the speed The electronic clutch mode regular rotation rotates the motor at a very slow speed for a certain period after the start and then increases the speed 12
