13
CUTTING A HOLE IN MATERIAL
• Make a hole in processed material with 10 mm diameter.
• Put blade into the hole and start cutting from that spot.
METAL CUTTING / TYPES OF BLADES
Use appropriate blades with more teeth for cutting of metal.
For metal cutting use appropriate lubricant (e.g. cutting oil). Metal
cutting without lubrication leads to rapid wear of blade. The below
table gives the best choices for blade type:
Teeth per
inch
Blade length
Application range
24
80 mm
Soft steel, non-ferrous metals
14 Non-ferrous metals, plastics
9 Wood, plywood
• Use only appropriate and sharp blades.
• Do not use blades with damaged shank.
• Use appropriate blade types.
OPERATION AND MAINTENANCE
Unplug the power cord from mains socket before commencing
any activities related to installation, adjustment, repair or
maintenance.
• Cleaning the device after each use is recommended.
• Do not use water or any other liquid for cleaning.
• Clean the device with a dry cloth or blow through with
compressed air at low pressure.
• Do not use any cleaning agents or solvents, since they may
damage plastic parts.
• Clean ventilation holes in the motor casing regularly to prevent
device overheating.
• Regular lubrication of guiding roller is recommended. A drop of oil
applied in this spot will prolong lifetime of the roller.
• In case of power cord damage replace it with a cord with the same
specication. Entrust the repair to a qualied specialist or return
the tool to a service point.
• In case of excessive commutator sparking, have the technical
condition of carbon brushes of the motor checked by a qualied
person.
• always store the tool in a dry place, beyond reach of children.
REPLACEMENT OF CARBON BRUSHES
Immediately replace worn out (shorter than 5 mm), burnt or
cracked motor carbon brushes. always replace both carbon
brushes at a time.
Entrust replacement of carbon brushes only to a qualied person.
Use only original parts.
All defects should be repaired by service workshop authorized by
the manufacturer.
TECHNICAL PARAMETERS
RATED PARAMETERS
Jigsaw 58G067
Parameter Value
Supply voltage 230 V AC
Power supply frequency 50 Hz
Rated power 650 W
Blade stroke cycles (without load) 0-3100 min
-1
Maximum
thickness of
cut material
Wood 65 mm
Metal 8 mm
Blade stroke length 18 mm
Protection class II
Weight 2,1 kg
Year of production 2019
58G067 denes type and indication of the device
NOISE LEVEL AND VIBRATION PARAMETERS
Sound pressure Lp
A
= 84,6 dB(A) K= 3 dB(A)
Sound power Lw
A
= 95,6 dB(A) K= 3 dB(A)
Vibration acceleration (cutting
a plate)
a
h
= 4,535 m/s² K= 1,5 m/s²
Vibration acceleration (cutting
a metal sheet)
a
h
= 4,008 m/s² K= 1,5 m/s²
Noise and vibration information
Noise produced by the device is dened with: level of produced
sound pressure Lp
A
and level of sound power Lw
A
(where K is
measurement uncertainty). Vibrations produced by the device
are dened with vibration acceleration value a
h
(where K is
measurement uncertainty).
Sound pressure Lp
A
, sound power Lw
A
and vibration acceleration a
h
specied in this manual have been measured in accordance with EN
62841-1:2015. Specied vibration level a
h
can be used to compare
tools and for initial evaluation of exposition to vibrations.
Specied vibration level is representative only for main applications
of the device. When the device is used for other purposes or with
dierent working tools, the vibration level may change. Insucient
or too rare maintenance may increase vibration level. The
abovementioned factors may lead to higher exposure to vibrations
during whole working time.
In order to precisely dene exposure to vibrations, include
periods when the device is switched o and when it is switched
on but not used for working. Once all factors have been carefully
considered, total exposition to vibrations may be signicantly
lower.
To protect the user from results of exposure to vibrations, use
additional safety measures such as: device and working tool periodic
maintenance, proper hand temperature conditions, good work
organisation.
ENVIRONMENTAL PROTECTION
Electrical equipment must not be disposed o with household
waste and, instead, should be utilized at appropriate facilities.
Information on utilization can be provided by the product
vendor or the local authorities. Waste electrical and electronic
equipment contains substances that are not neutral to
the natural environment. Equipment that is not recycled
constitutes a potential hazard to the environment and to
human health.
* Right to introduce changes is reserved.
