Hitachi DS14DCL-RА [13/84] English

English

CAUTION

䡬 The selection examples shown in Table 5 should

be considered as general standard. As different

types of tightening screws and different materials

to be tightened are used in actual works proper

adjustments are naturally necessary.

䡬 When using the driver drill with a machine screw

at HIGH (high speed), a screw may damage or a

bit may loose due to the tightening torque is too

strong. Use the driver drill at LOW (low speed)

when using a machine screw.

NOTE:

The use of the battery BCL1415 and BCL1815 in a

cold condition (below 0 degree Centigrade) can

sometimes result in the weakened tightening torque

and reduced amount of work. This, however, is

a temporary phenomenon, and returns to normal

when the battery warms up.

6. Mounting and dismounting of the bit

(1) After inserting a driver bit, etc. into the keyless drill

chuck, firmly grasp the ring and tighten the sleeve

by turning it toward the right (in the clockwise

direction as viewed from the front) (See Fig. 8).

䡬 If the sleeve becomes loose during operation, tighten

it further. The tightening force becomes stronger

when the sleeve is tightened additionally.

(2) Dismounting the bit

Firmly grasp the ring and loosen the sleeve by

turning it toward the left (in the counter-clockwise

direction as viewed from the front) (See Fig. 8).

CAUTION

䡬 When it is no longer possible to loosen the sleeve,

use a vise or similar instrument to secure the bit. Set

the clutch mode between 1 and 11, and then turn

the sleeve to the loose side (left side) while operating

the clutch. It should be easy now to loosen the sleeve.

7. Confirm that the battery is mounted correctly

8. Check the rotational direction

The bit rotates clockwise (viewed from the rear

side) by pushing the R-side of the selector button.

The L-side of the selector button is pushed to turn

the bit counterclockwise (See Fig. 9) (The

and

marks are provided on the body).

9. Switch operation

䡬 When the trigger switch is depressed, the tool

rotates. When the trigger is released, the tool stops.

䡬 The rotational speed of the drill can be controlled by

varying the amount that the trigger switch is pulled.

Speed is low when the trigger switch is pulled slightly

and increases as the trigger switch is pulled more.

NOTE

䡬 A buzzing noise is produced when the motor is about

to rotate; This is only a noise, not a machine failure.

10. Using the bit holder

CAUTION

䡬 Stow the bit in the specified location on the tool.

If the tool is used with the bit stowed improperly,

the bit may fall and cause bodily injury.

䡬 Do not stow bits that are of a different length,

gauge or dimension than the plus driver bit (65 mm

long) included in the STANDARD ACCESSORIES.

The bit may fall and cause bodily injury.

(1) Removing the bit

Securely hold the main unit and pull out the bit

by holding the tip with your thumb (Fig. 10).

(2) Installing the Bit

Install the bit with steps opposite of when removing.

Insert the bit so that the right and left sides are

equal, as shown in Fig. 11.

MAINTENANCE AND INSPECTION

1. Inspecting the tool

Since use of as dull tool will degrade efficiency and

cause possible motor malfunction, sharpen or

replace the tool as soon as abrasion is noted.

2. Inspecting the mounting screws

Regularly inspect all mounting screws and ensure

that they are properly tightened. Should any of the

screws be loose, retighten them immediately. Failure

to do so could result in serious hazard.

3. Cleaning on the outside

When the driver drill is stained, wipe with a soft

dry cloth or a cloth moistened with soapy water.

Do not use chloric solvents, gasoline or paint thinner,

for they melt plastics.

4. Storage

Store the driver drill in a place in which the temperature

is less than 40°C and out of reach of children.

5. Service parts list

CAUTION

Repair, modification and inspection of Hitachi Power

Tools must be carried out by a Hitachi Authorized

Service Center.

This Parts List will be helpful if presented with the

tool to the Hitachi Authorized Service Center when

requesting repair or other maintenance.

In the operation and maintenance of power tools,

the safety regulations and standards prescribed in

each country must be observed.

MODIFICATIONS

Hitachi Power Tools are constantly being improved

and modified to incorporate the latest technological

advancements.

Accordingly, some parts may be changed without

prior notice.

Important notice on the batteries for the Hitachi

cordless power tools

Please always use one of our designated genuine

batteries. We cannot guarantee the safety and

performance of our cordless power tool when

used with batteries other than these designated

by us, or when the battery is disassembled and

modified (such as disassembly and replacement

of cells or other internal parts).

GUARANTEE

We guarantee Hitachi Power Tools in accordance with

statutory/country specific regulation. This guarantee

does not cover defects or damage due to misuse,

abuse, or normal wear and tear. In case of complaint,

please send the Power Tool, undismantled, with the

GUARANTEE CERTIFICATE found at the end of this

Handling instruction, to a Hitachi Authorized Service

Center.

01Eng_DS14DCL_EE 11/18/09, 15:5912
