Contents - Maintenance Page
Maintenance .................................................................................................................................20
Key to maintenance intervals ..............................................................................................20
Reading out MoDiTeC fault memory ...............................................................................20
(Inspections I, II, III and IV)
Changing engine oil, replacing oil filter element ......................................................20
(Inspections I, II, III and IV)
Changing oil in gearbox ..........................................................................................................21
(Inspections III and IV)
or every 2 years at the latest
Changing oil in rear wheel drive; cleaning inductive signal transmitter at
rear wheel .......................................................................................................................................22
(Inspections I, III and IV)
Every 40 000 km (24 000 miles) or every 2 years at the latest
Replacing fuel filter ...................................................................................................................23
(Inspection III)
In normal operating conditions every 40 000 km (24 000 miles); if fuel quality is poor every
20 000 km (12 000 miles)
Checking battery fluid level and
topping up if necessary; cleaning and greasing the battery posts .................25
(Inspections III and IV)
Replacing intake air filter element ....................................................................................25
(Inspection III)
In very dirty and dusty operating conditions, replace every 10 000 km (6 000 miles) or even more fre-
quently if necessary
Replacing Poly-V belt ...............................................................................................................26
(every 60 000 km/36 000 miles)
(Inspection III)
Poly-V belt adjusting procedure:
Checking brake fluid level .....................................................................................................27
Front brake ......................................................................................................................................27
Rear brake .......................................................................................................................................27
Checking brake pads and discs for wear/replacing ...............................................28
(Inspections II and III)
Checking front brake pad wear ..............................................................................................28
Checking rear brake pad wear ...............................................................................................28
Checking brake disc wear ........................................................................................................28
Replacing brake pads, front brake .......................................................................................29
Replacing brake pads, rear brake .........................................................................................29
Maintenance
