00.34
e Caution:
The motorcycle is not permitted on the road without
the grubscrew in place and secure in the filler adapt-
er.
•
Correct the fluid level.
•
Place the reservoir cover with rubber diaphragm
in position.
•
Tighten the reservoir cover without using force.
X Tightening torque:
Grubscrew in filler adapter ........................... 10 Nm
Consumables
Brake fluid.....................................................DOT 4
Checking tightness of rear wheel
studs
(Inspection I)
•
Check security of the rear wheel studs with a
torque wrench.
X Tightening torque:
Rear wheel studs ....................................... 105 Nm
Checking rear wheel bearing play by
tilting wheel
(Inspection III)
•
Tilt the rear wheel to and fro across its axle.
•
If play is detected, fit new shims to rear wheel
drive or replace bearings.
Checking swinging arm bearings,
adjusting if necessary
(Inspections I and III)
•
Grip rear tyre and try to move it sideways, brac-
ing against the frame.
