English | 13
Bosch Power Tools 2 610 016 854 | (20.9.11)
Product Description and Specifica-
tions
Read all safety warnings and all instruc-
tions. Failure to follow the warnings and in-
structions may result in electric shock, fire
and/or serious injury.
While reading the operating instructions, unfold the graphics
page for the machine and leave it open.
Intended Use
The machine is intended for driving in and loosening screws
as well as for drilling in wood, metal, ceramic and plastic, es-
pecially at hard to reach locations.
Product Features
The numbering of the product features refers to the illustra-
tion of the machine on the graphics page.
1 “PowerLight”
2 Keyless chuck
3 Rotational direction switch
4 On/Off switch
5 Release button for angle selection of drill head
6 Battery charge-control indicator
7 Battery unlocking button*
8 Battery*
9 Handle (insulated gripping surface)
10 Screwdriver bit*
11 Universal bit holder*
*Accessories shown or described are not part of the standard de-
livery scope of the product. A complete overview of accessories
can be found in our accessories program.
Technical Data
Noise/Vibration Information
Measured sound values determined according to EN 60745.
Typically the A-weighted sound pressure level of the product
is 72 dB(A). Uncertainty K=3 dB.
The noise level when working can exceed 80 dB(A).
Wear hearing protection!
Vibration total values a
h
(triax vector sum) and uncertainty K
determined according to EN 60745:
Drilling into metal: a
h
=3.5m/s
2
, K =1.5 m/s
2
,
Screwdriving: a
h
=3.5m/s
2
, K =1.5 m/s
2
.
The vibration emission level given in this information sheet
has been measured in accordance with a standardised test
given in EN 60745 and may be used to compare one tool with
another. It may be used for a preliminary assessment of expo-
sure.
The declared vibration emission level represents the main ap-
plications of the tool. However if the tool is used for different
applications, with different accessories or poorly maintained,
the vibration emission may differ. This may significantly in-
crease the exposure level over the total working period.
An estimation of the level of exposure to vibration should also
take into account the times when the tool is switched off or
when it is running but not actually doing the job. This may sig-
nificantly reduce the exposure level over the total working pe-
riod.
Identify additional safety measures to protect the operator
from the effects of vibration such as: maintain the tool and the
accessories, keep hands warm, organise work patterns.
Declaration of Conformity
We declare under our sole responsibility that the product de-
scribed under “Technical Data” is in conformity with the fol-
lowing standards or standardization documents: EN 60745
according to the provisions of the directives 2011/65/EU,
2004/108/EC, 2006/42/EC.
Technical file (2006/42/EC) at:
Robert Bosch GmbH, PT/ETM9,
D-70745 Leinfelden-Echterdingen
Robert Bosch GmbH, Power Tools Division
D-70745 Leinfelden-Echterdingen
20.09.2011
Assembly
Battery Charging (see figure A)
f Use only the battery chargers listed on the accessories
page. Only these battery chargers are matched to the lith-
ium ion battery of your power tool.
Cordless angle drill/driver GWB 10,8-LI
Professional
Article number 3 601 C90 9..
Rated voltage
V= 10.8
No-load speed
min
-1
0–1300
Max. torque for hard/soft screw-
driving application according to
ISO 5393 Nm 11/3
Max. screw dia.
mm 6
Max. drilling dia.
– Steel
– Wood
mm
mm
10
10
Weight according to
EPTA-Procedure 01/2003 kg 1.2
Please observe the article number on the type plate of your machine.
The trade names of the individual machines may vary.
Dr. Egbert Schneider
Senior Vice President
Engineering
Dr. Eckerhard Strötgen
Engineering Director
PT/ESI
OBJ_BUCH-1476-002.book Page 13 Tuesday, September 20, 2011 12:10 PM
