Chapter 17 Link Aggregation
GS2210 Series User’s Guide
154
Figure 111 Advanced Application > Link Aggregation > Link Aggregation Setting > LACP
The following table describes the labels in this screen.
Table 63 Advanced Application > Link Aggregation > Link Aggregation Setting > LACP
LABEL DESCRIPTION
Link
Aggregation
Control
Protocol
Note: Do not configure this screen unless you want to enable dynamic link aggregation.
Active Select this checkbox to enable Link Aggregation Control Protocol (LACP).
