Chapter 24 Multicast
GS2210 Series User’s Guide
200
Figure 141 Advanced Application > Multicast > IPv6 Multicast > MLD Snooping-proxy > Port Role
Setting
The following table describes the fields in the above screen.
Table 86 Advanced Application > Multicast > IPv6 Multicast > MLD Snooping-proxy > Port Role
Setting
LABEL DESCRIPTION
MLD Snooping-proxy
VLAN ID
Select the VLAN ID for which you want to configure a port’s MLD snooping-proxy
settings.
Port This field displays the port number.
* Settings in this row apply to all ports.
Use this row only if you want to make some settings the same for all ports. Use this
row first to set the common settings and then make adjustments on a port-by-port
basis.
Changes in this row are copied to all the ports as soon as you make them.
